⛓️ Langflow Integration
Langflow (GitHub) is a UI for LangChain, designed with react-flow to provide an effortless way to experiment and prototype flows.
With the native integration (since langflow v1.0.17), you can use Langflow to quickly create complex LLM applications in no-code and then use Litefuse to monitor and improve them.
Integration
Video guide on how to integrate Langflow with Litefuse (published by Langflow)
Get Litefuse API keys
- Create account and project on cloud.litefuse.ai
- Copy API keys for your project
Setup Langflow
# API keys from project settings in Langfuse
export LANGFUSE_SECRET_KEY=sk-lf...
export LANGFUSE_PUBLIC_KEY=pk-lf...
export LANGFUSE_HOST="https://litefuse.cloud"
# export LANGFUSE_HOST="http://localhost:3000" # 🏠 for self-hosters
# Install Langflow
pip install langflow
# Start Langflow in the same terminal or environment where you set the environment variables:
python -m langflow runAlternatively, you can run the Langflow CLI command with the environment variables set:
LANGFUSE_SECRET_KEY=secret_key LANGFUSE_PUBLIC_KEY=public_key LANGFUSE_HOST="http://localhost:3000" langflowSee your traces in Litefuse
Now, when you use Langflow’s chat or API, you can view the trace of your conversations in Litefuse.
Running Litefuse and Langflow with Docker Compose
If you prefer to self-host Litefuse, you can run both services using Docker Compose. By combining the two docker-compose files, you can streamline the networking between them.
version: "3.5"
services:
# Adapted from https://github.com/logspace-ai/langflow/blob/dev/docker_example/docker-compose.yml
langflow:
build:
context: .
dockerfile: Dockerfile
ports:
- "7860:7860"
environment:
+ # Tokens are to be created in Litefuse, then copy-pasted here. Then restart docker-compose.
+ - LANGFUSE_SECRET_KEY=sk-lf-...
+ - LANGFUSE_PUBLIC_KEY=pk-lf-...
+ - LANGFUSE_HOST="http://langfuse-server:3000"
command: langflow run --host 0.0.0.0
# https://github.com/litefuse/litefuse/blob/main/docker-compose.yml
litefuse-worker:
image: litefuse/litefuse-worker:3
restart: always
depends_on: &litefuse-depends-on
postgres:
condition: service_healthy
minio:
condition: service_healthy
redis:
condition: service_healthy
doris_fe:
condition: service_healthy
doris_be:
condition: service_healthy
ports:
- 127.0.0.1:3030:3030
environment: &litefuse-worker-env
NEXTAUTH_URL: http://localhost:3000
DATABASE_URL: postgresql://postgres:postgres@postgres:5432/postgres # CHANGEME
SALT: "mysalt" # CHANGEME
ENCRYPTION_KEY: "0000000000000000000000000000000000000000000000000000000000000000" # CHANGEME: generate via `openssl rand -hex 32`
TELEMETRY_ENABLED: ${TELEMETRY_ENABLED:-true}
LANGFUSE_ENABLE_EXPERIMENTAL_FEATURES: ${LANGFUSE_ENABLE_EXPERIMENTAL_FEATURES:-true}
# Note: Doris is enabled automatically when LANGFUSE_ANALYTICS_BACKEND="doris"
LANGFUSE_ANALYTICS_BACKEND: ${LANGFUSE_ANALYTICS_BACKEND:-doris}
DORIS_URL: ${DORIS_FE_HTTP_URL:-}
DORIS_FE_HTTP_URL: ${DORIS_FE_HTTP_URL:-http://172.30.0.2:8030}
DORIS_FE_QUERY_PORT: ${DORIS_FE_QUERY_PORT:-9030}
DORIS_DB: ${DORIS_DB:-langfuse}
DORIS_USER: ${DORIS_USER:-root}
DORIS_PASSWORD: ${DORIS_PASSWORD:-}
DORIS_MAX_OPEN_CONNECTIONS: ${DORIS_MAX_OPEN_CONNECTIONS:-100}
DORIS_REQUEST_TIMEOUT_MS: ${DORIS_REQUEST_TIMEOUT_MS:-30000}
HOSTNAME: "0.0.0.0"
PORT: "3000"
LANGFUSE_S3_EVENT_UPLOAD_BUCKET: ${LANGFUSE_S3_EVENT_UPLOAD_BUCKET:-langfuse}
LANGFUSE_S3_EVENT_UPLOAD_REGION: ${LANGFUSE_S3_EVENT_UPLOAD_REGION:-auto}
LANGFUSE_S3_EVENT_UPLOAD_ACCESS_KEY_ID: ${LANGFUSE_S3_EVENT_UPLOAD_ACCESS_KEY_ID:-minio}
LANGFUSE_S3_EVENT_UPLOAD_SECRET_ACCESS_KEY: ${LANGFUSE_S3_EVENT_UPLOAD_SECRET_ACCESS_KEY:-miniosecret} # CHANGEME
LANGFUSE_S3_EVENT_UPLOAD_ENDPOINT: ${LANGFUSE_S3_EVENT_UPLOAD_ENDPOINT:-http://minio:9000}
LANGFUSE_S3_EVENT_UPLOAD_FORCE_PATH_STYLE: ${LANGFUSE_S3_EVENT_UPLOAD_FORCE_PATH_STYLE:-true}
LANGFUSE_S3_EVENT_UPLOAD_PREFIX: ${LANGFUSE_S3_EVENT_UPLOAD_PREFIX:-events/}
LANGFUSE_S3_MEDIA_UPLOAD_BUCKET: ${LANGFUSE_S3_MEDIA_UPLOAD_BUCKET:-langfuse}
LANGFUSE_S3_MEDIA_UPLOAD_REGION: ${LANGFUSE_S3_MEDIA_UPLOAD_REGION:-auto}
LANGFUSE_S3_MEDIA_UPLOAD_ACCESS_KEY_ID: ${LANGFUSE_S3_MEDIA_UPLOAD_ACCESS_KEY_ID:-minio}
LANGFUSE_S3_MEDIA_UPLOAD_SECRET_ACCESS_KEY: ${LANGFUSE_S3_MEDIA_UPLOAD_SECRET_ACCESS_KEY:-miniosecret} # CHANGEME
LANGFUSE_S3_MEDIA_UPLOAD_ENDPOINT: ${LANGFUSE_S3_MEDIA_UPLOAD_ENDPOINT:-http://localhost:9090}
LANGFUSE_S3_MEDIA_UPLOAD_FORCE_PATH_STYLE: ${LANGFUSE_S3_MEDIA_UPLOAD_FORCE_PATH_STYLE:-true}
LANGFUSE_S3_MEDIA_UPLOAD_PREFIX: ${LANGFUSE_S3_MEDIA_UPLOAD_PREFIX:-media/}
LANGFUSE_S3_BATCH_EXPORT_ENABLED: ${LANGFUSE_S3_BATCH_EXPORT_ENABLED:-false}
LANGFUSE_S3_BATCH_EXPORT_BUCKET: ${LANGFUSE_S3_BATCH_EXPORT_BUCKET:-langfuse}
LANGFUSE_S3_BATCH_EXPORT_PREFIX: ${LANGFUSE_S3_BATCH_EXPORT_PREFIX:-exports/}
LANGFUSE_S3_BATCH_EXPORT_REGION: ${LANGFUSE_S3_BATCH_EXPORT_REGION:-auto}
LANGFUSE_S3_BATCH_EXPORT_ENDPOINT: ${LANGFUSE_S3_BATCH_EXPORT_ENDPOINT:-http://minio:9000}
LANGFUSE_S3_BATCH_EXPORT_EXTERNAL_ENDPOINT: ${LANGFUSE_S3_BATCH_EXPORT_EXTERNAL_ENDPOINT:-http://localhost:9090}
LANGFUSE_S3_BATCH_EXPORT_ACCESS_KEY_ID: ${LANGFUSE_S3_BATCH_EXPORT_ACCESS_KEY_ID:-minio}
LANGFUSE_S3_BATCH_EXPORT_SECRET_ACCESS_KEY: ${LANGFUSE_S3_BATCH_EXPORT_SECRET_ACCESS_KEY:-miniosecret} # CHANGEME
LANGFUSE_S3_BATCH_EXPORT_FORCE_PATH_STYLE: ${LANGFUSE_S3_BATCH_EXPORT_FORCE_PATH_STYLE:-true}
LANGFUSE_INGESTION_QUEUE_DELAY_MS: ${LANGFUSE_INGESTION_QUEUE_DELAY_MS:-}
LANGFUSE_INGESTION_CLICKHOUSE_WRITE_INTERVAL_MS: ${LANGFUSE_INGESTION_CLICKHOUSE_WRITE_INTERVAL_MS:-}
REDIS_HOST: ${REDIS_HOST:-redis}
REDIS_PORT: ${REDIS_PORT:-6379}
REDIS_AUTH: ${REDIS_AUTH:-myredissecret} # CHANGEME
REDIS_TLS_ENABLED: ${REDIS_TLS_ENABLED:-false}
REDIS_TLS_CA: ${REDIS_TLS_CA:-/certs/ca.crt}
REDIS_TLS_CERT: ${REDIS_TLS_CERT:-/certs/redis.crt}
REDIS_TLS_KEY: ${REDIS_TLS_KEY:-/certs/redis.key}
litefuse-web:
image: litefuse/litefuse:3
restart: always
depends_on: *litefuse-depends-on
ports:
- 3000:3000
environment:
<<: *litefuse-worker-env
NEXTAUTH_SECRET: mysecret # CHANGEME
LANGFUSE_INIT_ORG_ID: ${LANGFUSE_INIT_ORG_ID:-}
LANGFUSE_INIT_ORG_NAME: ${LANGFUSE_INIT_ORG_NAME:-}
LANGFUSE_INIT_PROJECT_ID: ${LANGFUSE_INIT_PROJECT_ID:-}
LANGFUSE_INIT_PROJECT_NAME: ${LANGFUSE_INIT_PROJECT_NAME:-}
LANGFUSE_INIT_PROJECT_PUBLIC_KEY: ${LANGFUSE_INIT_PROJECT_PUBLIC_KEY:-}
LANGFUSE_INIT_PROJECT_SECRET_KEY: ${LANGFUSE_INIT_PROJECT_SECRET_KEY:-}
LANGFUSE_INIT_USER_EMAIL: ${LANGFUSE_INIT_USER_EMAIL:-}
LANGFUSE_INIT_USER_NAME: ${LANGFUSE_INIT_USER_NAME:-}
LANGFUSE_INIT_USER_PASSWORD: ${LANGFUSE_INIT_USER_PASSWORD:-}
doris_fe:
image: apache/doris:fe-2.1.11
hostname: doris_fe
container_name: doris_fe
environment:
- FE_SERVERS=fe1:172.30.0.2:9010
- FE_ID=1
ports:
- "8030:8030"
- "9030:9030"
- "9010:9010"
networks:
doris_internal:
ipv4_address: 172.30.0.2
volumes:
- doris_fe_meta:/opt/apache-doris/fe/doris-meta
# - ./doris-config/fe_custom.conf:/opt/apache-doris/fe/conf/fe_custom.conf:ro
healthcheck:
test: [ "CMD-SHELL", "mysql -h 127.0.0.1 -P 9030 -uroot -e 'SELECT 1' 2>/dev/null || exit 1" ]
interval: 10s
timeout: 5s
retries: 18
start_period: 120s
doris_be:
image: apache/doris:be-2.1.11
hostname: doris_be
container_name: doris_be
environment:
- FE_SERVERS=fe1:172.30.0.2:9010
- BE_ADDR=172.30.0.3:9050
depends_on:
doris_fe:
condition: service_healthy
ports:
- "8040:8040"
- "8060:8060"
- "9050:9050"
- "9060:9060"
networks:
doris_internal:
ipv4_address: 172.30.0.3
volumes:
- doris_be_storage:/opt/apache-doris/be/storage
# - ./be_custom.conf:/opt/apache-doris/be/conf/be_custom.conf:ro
restart: unless-stopped
healthcheck:
test: [ "CMD-SHELL", "mysql -h 172.30.0.2 -P 9030 -uroot -e 'SHOW BACKENDS\\G' | grep -A 20 'Host: 172.30.0.3' | grep -q 'Alive: true'" ]
interval: 10s
timeout: 5s
retries: 5
start_period: 150s
minio:
image: minio/minio
restart: always
entrypoint: sh
# create the 'langfuse' bucket before starting the service
command: -c 'mkdir -p /data/langfuse && minio server --address ":9000" --console-address ":9001" /data'
environment:
MINIO_ROOT_USER: minio
MINIO_ROOT_PASSWORD: miniosecret # CHANGEME
ports:
- 9090:9000
- 127.0.0.1:9091:9001
volumes:
- langfuse_minio_data:/data
healthcheck:
test: ["CMD", "mc", "ready", "local"]
interval: 1s
timeout: 5s
retries: 5
start_period: 1s
redis:
image: redis:7
restart: always
# CHANGEME: row below to secure redis password
command: >
--requirepass ${REDIS_AUTH:-myredissecret}
ports:
- 127.0.0.1:6379:6379
healthcheck:
test: ["CMD", "redis-cli", "ping"]
interval: 3s
timeout: 10s
retries: 10
postgres:
image: postgres:${POSTGRES_VERSION:-latest}
restart: always
healthcheck:
test: ["CMD-SHELL", "pg_isready -U postgres"]
interval: 3s
timeout: 3s
retries: 10
environment:
POSTGRES_USER: postgres
POSTGRES_PASSWORD: postgres # CHANGEME
POSTGRES_DB: postgres
ports:
- 127.0.0.1:5432:5432
volumes:
- langfuse_postgres_data:/var/lib/postgresql/data
volumes:
langfuse_postgres_data:
driver: local
langfuse_minio_data:
driver: local
doris_fe_meta:
driver: local
doris_be_storage:
driver: localTo test the connectivity between Langflow and Litefuse, run the following command:
docker compose exec langflow python -c "import requests, os; addr = os.environ.get('LANGFUSE_HOST'); print(addr); res = requests.get(addr, timeout=5); print(res.status_code)"
# which should output the following:
# http://litefuse-server:3000
# 200Was this page helpful?
